Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Yongxing
- Model Number:
- KCD2-21
- Max. Current:
- 16A
- Max. Voltage:
- 250VAC
- Mechanical Life:
- 100000 Cycles
- Certifiation:
- CQC, CE, RoHS, UL, ENEC, CB
- Function:
- DPST
- Contact Resistance:
- ≤50mΩ
- Insulation Resistance:
- ≥1000mΩ
- dielectric strength:
- 1500V AC ,1min
- Operating Temperature:
- T55,T85,T125
- pins:
- 4
- IP Rating:
- IP44
- Name:
- factory price dpst 4 pin on off 16a 250v rocker switch kcd2
- Material:
- PA66
Supply Ability
- Supply Ability:
- 1000000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 100 pcs in one poly bag and then put into master carton
- Port
- Shanghai
- Lead Time:
Quantity(Pieces) 1 - 2000 >2000 Est. Time(days) 20 To be negotiated
