Overview
Quick Details
- Brand Name:
- SK(ShangKai)
- Model Number:
- KCD
- Max. Current:
- 16A
- Max. Voltage:
- 250V AC
- Mechanical Life:
- 100,000
- Certifiation:
- CQC, CE, RoHS, UL, CB, ENEC
- Color:
- red green yellow white blue orange black gray coffee
- Contact Resistance:
- ≤50mΩ
- Insulation Resistance:
- ≥1000mΩ
- dielectric strength:
- 1500V AC ,1min
- Function:
- dpst dpdt dptt
- pins:
- 4 pin/6 pin
- IP code:
- ip40/ip65
Supply Ability
- Supply Ability:
- 700000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 100 pieces in one box,2000 pieces in one Standard export carton
- Port
- Shanghai
- Lead Time:
Quantity(Pieces) 1 - 1000 >1000 Est. Time(days) 20 To be negotiated
