Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Shanghai Yongxing
- Model Number:
- AX16-113-3
- Max. Current:
- 3A
- Max. Voltage:
- 250V AC
- Mechanical Life:
- 50000
- Color:
- Black
- Function:
- 3 Position
- Insulation resistance:
- 100m
- IP code:
- IP40
- Operating temperature:
- -25~+55
- max.rating cnrrent&voltage:
- 3A 250vac
- contact resistance:
- <50mΩ
- insulation resistance:
- ≥100MΩ
- dielectrice resistance:
- 1,500V,1min
- operating temperature:
- -25℃-55℃
Supply Ability
- Supply Ability:
- 1000000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 25 pcs in one pvc box and then put in master carton
- Port
- Shanghai port
- Picture Example:
- Lead Time:
Quantity(Pieces) 1 - 2000 >2000 Est. Time(days) 25 To be negotiated
