Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Shanghai Yongxing
- Model Number:
- KCD1-11-FA1A-B-B-01
- Max. Current:
- 16A
- Max. Voltage:
- 250VAC
- Mechanical Life:
- 100000
- Color:
- Blcak
- Certificate:
- CQC,CE,UL,CB,ENEC17
- Function:
- SPST
- Product type:
- Rocker Switch T125 55
- pins:
- 2
- Contact Resistance:
- ≤50MΩ
- Insulation resistance:
- ≥1000MΩ
- Dielectric Strength:
- 1500V AC , 1min
- Electronic Life:
- 10,000 cycles
- Operating Temperature:
- T55 T85 T125
Supply Ability
- Supply Ability:
- 1000000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 100 pcs in one poly bag and then put in master carton
- Port
- Shanghai port
- Picture Example:
- Lead Time:
Quantity(Pieces) 1 - 2000 >2000 Est. Time(days) 25 To be negotiated
