Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Shiningkey(SK)
- Model Number:
- RS2-24D rotary switches
- Max. Current:
- 16A
- Max. Voltage:
- 250V AC
- Mechanical Life:
- 100,000
- Name:
- CQC ENEC T125 limit z5 series electric power tool rotary switches
- Certification:
- CQC, RoHS, ENEC
- Color:
- Black
- Type:
- RS2-24D rotary switch
- Pins:
- 5 pin rotary switch
- Operating temperature:
- T125
- dielectric resistance:
- 1500V
- ContactResistance:
- ≤50mΩ
- Insulation resistance:
- ≥100mΩ
- Electronic life:
- 50,000cycles
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 40X40X40 cm
- Gross weight per batch:
- 0.9 kg
- Package Type:
- CQC ENEC T125 limit z5 series electric power tool rotary switchesof 50Pieces in one bag,1000pieces in one Standard export carton , rotary dip switch .
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 20000 >20000 Est. Time(days) 20 To be negotiated
