Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- SK(Shangkai)
- Model Number:
- KCD8
- Max. Current:
- 6A/10A
- Max. Voltage:
- 250V AC
- Mechanical Life:
- 100,000 Cycles
- name:
- 6a 10a 250v cqc 2 pin 3 pin 12v round rocker switch
- Description:
- SPST
- pins:
- 2 pin 3 pin
- Color:
- Black on off on rocker switch
- Contact Resistance:
- ≤50m Ω
- Insulation Resistance:
- ≥1,000MΩ rocker switch
- Electronic Life(cycles):
- 10000 cycles
- The Crust Material:
- Plastic waterproof rocker switch
- Certification:
- CQC , CE , RoHS , ENEC , UL , CB
Supply Ability
- Supply Ability:
- 1000000 Piece/Pieces per Month 6a 10a 250v cqc 2 pin 3 pin 12v round rocker switch
Packaging & Delivery
- Packaging Details
- 6a 10a 250v cqc 2 pin 3 pin 12v round rocker switch
100 pieces in onebag and then put into master carton
- Port
- Shanghai
- Lead Time:
Quantity(Pieces) 1 - 3000 >3000 Est. Time(days) 20 To be negotiated
