Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- SK(ShangKai)
- Model Number:
- YC
- Number of Contacts:
- 2-24poles
- Conductor Size:
- 28-14AWG
- Type:
- Plug-in
- Color:
- Red, Yellow ,Green, Black, White, Blue
- Certification:
- CQC
- Current:
- 10A
- Voltage:
- 300V high current connector
- Pole:
- 2-24poles
- Operation temperature:
- -40℃~+150℃
- Withstanding voltage:
- AC2000V/Min
- Housing:
- PA66,UL94V-0
- insulation resistance:
- >5000MΩ DC500V
- Poles:
- 2-24ploles
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 40X40X40 cm
- Gross weight per batch:
- 0.7 kg
- Package Type:
- 7.5mm 2 way terminal block plastic terminal block plug in terminal block 50pieces in one box,1000pieces in one standard export carton
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 3000 >3000 Est. Time(days) 25 To be negotiated
