- Place of Origin:
- Shanghai, China
- Brand Name:
- SK(ShangKai)
- Model Number:
- KW15
- Max. Current:
- 16A
- Max. Voltage:
- 250V AC
- Operating Temperature:
- -25°~+125°
- Protection Level:
- IP40 , IP65
- Name:
- Yongxing KW15
- Color:
- Black , Gray
- Current:
- 3A~16A
- ContactResistance:
- ≤50mΩ
- INSULATION RESISTANCE:
- ≥100mΩ
- dielectronic strength:
- 1,500V
- electronic life(cycles):
- 50,000
- operating temperature:
- -25℃~+125℃
- Certification:
- ENEC , CQC
- IP:
- IP40 , IP65
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 40X40X40 cm
- Gross weight per batch:
- 1.004 kg
- Package Type:
- On off latching low voltage normally close symbol 40t85 1e4 20a 250vac 25t125 micro switch of 50 pieces one plister box,1000 pieces in one carton, micro switch 20a 250vac 25t125
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 30000 >30000 Est. Time(days) 20 To be negotiated
On off latching low voltage normally close symbol 20a 25t125 micro switch
| IP code | IP40 , IP65 |
| Color | Black |
| Current | 3A~16A |
| Voltage | 125V~250V |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100mΩ |
| Dielectronic Strength | 1500V |
| electronic life(cycles) | 50,000 |
| operating temperature | -25℃~+125℃ |
| Certification | ENEC , UL , CQC |
We insist on the BEST Quality.Company with CONFIDENCE.
We insist on the BEST Quality. Company with CONFIDENCE.
Let more and more global buyers approve high quality products made in China.
It has passed the certification of ISO9001:2008 Quality Management System and many of its products have passed the quality certification of authoritative certification bodies such as CQC,UL and ENEC,CE,ROHS.
Q1: How many kinds of electric current for micro switch?
A: We provide two type is 16A and 5A.
Q2: How payment?
A:(1) Safe payment terms: T/T
(2) We offer EXW, FOB, CIF, etc.
Q3:What’s your mainly products?
A:We Produce and sell high quality electronic switches, more than 20 categories, including pushbutton switches, rocker switches, rotary switches, key lock switches, dip switches, slide switches, refrigerator switches, micro and mini switches, indicators, buzzes, terminal blocks, solenoid valves and so on.
Q4:How you will send the goods to us?
A:For urgent orders, we will send to your door by air. For bulk orders, it’s a good way send to you by sea but will take much time. For small orders, express will be best. We can send the goods to you by DHL, FEDEX, UPS, EMS etc.
