Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Shangkai(SK)
- Model Number:
- YB212-381-8P
- Number of Contacts:
- 1 - 10
- Conductor Size:
- 11 - 20 AWG
- Type:
- Screw
- color:
- Red, Yellow ,Green, Black, White, Blue, Gray, Orange
- Certification:
- CCC,CQC, CE, RoHS, ENEC, KEMA
- pole:
- 2-16poles
- Contact:
- Brass,Tin Plated
- withstanding voltage:
- AC2000V/1min
- insulation resistance:
- >5000MΩDC500V
- Temperature:
- -40℃~+150℃
- name:
- terminal connector auto connector electric wire connector
- Material:
- plastic terminal block
- Housing:
- PA66.UL94V-0
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 40X40X40 cm
- Gross weight per batch:
- 0.7 kg
- Package Type:
- 100pcs in a plastic bag, and then 10pcs bags in a carton box We can customize the carton box as your requirements.
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 300000 >300000 Est. Time(days) 25 To be negotiated
