Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- SK(ShangKai)
- Model Number:
- YE7340-500-12P
- Number of Contacts:
- 2-20
- Conductor Size:
- 28-12AWG
- Type:
- Plug-in
- Color:
- Red, Yellow ,Green, Black, White, Blue, Gray, Orange
- Certification:
- CCC,CQC, CE, RoHS, ENEC, UL,KEMA
- Pole:
- 2-20poles
- Pitch:
- 5.00mm
- Housing:
- PA66 UL94V-0
- Strip length:
- 6-7mm
- Operation temperature:
- -40℃~+150℃
- insulation resistance:
- >5000MΩ DC500V
- Short-time temperature:
- +250°Cfor5sec.
- Screws:
- M2.5steel Zinc plated
Supply Ability
- Supply Ability:
- 10000000 Piece/Pieces per Week lsa terminal block
Packaging & Delivery
- Packaging Details
- lsa terminal block PCB Plug terminal block terminal block
100Pieces in one box,1000pieces in one Standard export carton
- Port
- Shanghai
