-Printing resolation less than 50nm;
-Nanofiber highly oriented and controllable;
- International R & D team pioneering technology;
- Exclusive patented technology;
-Micro nano manufacture excellent tools
Near Electrospinning Technology Classification
Solution Near-field Electrospinning
Solution near-field electrospinning process, the printing material is prepared into a solution, and using electrostatic field print orientation nanofibers. It can produce a fiber orientation controllable fiber diameter range is 50nm-20μm, the solution electrospun near-field have more suitable materials.
Melt near-field electrospinning
melt Near-field electrospinning process, the printed material is heated and melted, assisted with the electrostatic field, fibers with a diameter range of 500nm-50μm can be prepared, high 3D printing capability, very suitable for producing three-dimensional biological tissue engineering scaffolds.
Near field electrospinning equipment parameters
High voltage power supply: 0-30kv, adjustable;
Solution spinning nozzle: solution supply volume at least 10μl/h;
Melt spinning nozzle: nozzle temperature: 0-300℃, adjustable, precision pneumatic extrusion;
Printing environment temperature: indoor temperature -50℃, adjustable;
Collection platform: printing range 150*150mm, platform speed: 0-200mm/s, resolution: 50nm;
Nozzle height: 0-80mm, adjustable, resolution: 50nm;
Printable materials: PE0, PVA, PLA, PCL, PLGA, chitosan, sodium alginate, collagen, hydroxyapatite, PVDF and other hundreds of organic or inorganic materials;
printable user-defined patterns;
printable 3D structure;
customizable : temperature controllable collector;
customizable : multi-nozzle device.
