Ultrasound-assisted Electrospinning Nanofiber Preparation Device
Ultrasound-assisted electrospinning nanofiber preparation device can manufacture many nanofiber materials with its simple structure and easy operation. It is composed by ultrasonic generator, electrospinning electrodes, electrospinning receiving electrodes, high-voltage supply, exhaust system, base material delivery, rewinding device and roll-pressing device; wherein the electrospinning electrode and the spinning solution are placed in the insulating groove, the insulating groove is placed in the ultrasonic generator water bath, and the receiving electrode is positioned over the spinning electrode and connected with the exhaust system. The receiving electrodes are in multiparous stainless steel plate structure. And electrospinning receiving base materials is provided by base material delivery and rewinding device on the surface of receiving electrode. The electrospinning nanofiber nonwoven fabric is rolled through a roll-pressing device and rolled through a rewind device. (The patent number of this invention: CN203096243U)
