Model

BK-EO

BK-TC

Sample capacity

96-PCR plate(full-skirted)

96*0.2ml tubes

12*8-strip

Cooling technology

Peltier-based

Display

LCD display and touch creen(5.7 inch)

6.5 inch,262 144 color LCD display and touch screen

Temp. Range

4.0-99.9℃

Heating speed of ramping

Up to 4℃/sec

Cooling speed of ramping

Up to 4℃/sec

Temp. uniformity

≤±0.3℃

≤±0.2℃

Temp. accuracy

≤±0.1℃(50℃), ≤±0.2℃ (≥90℃)

Temp. control modes

BLOCK or TUBE

Ramping range adjustable

0.1℃-4℃

Memory

≥250 typical programs onboard, unlimited with USB flash drive expansion

Max. No. of cycle

99. Suitable for nested PCR

Time up/down

0-9 min 59s, suitable for long PCR

Temp. up/down

0-9.9℃,suitable for touchdown PCR

Auto pause/power protection

YES

Soak function

Yes

Gradient range of temp. difference

1-30℃

Gradient range

30-99.9℃

Hot-lid Temp. range

Room temperature +5℃-110℃(default 105℃)

Height of hot-lid

Automatic Adjusted

Auto shut-off function of hot lid

While block temperature is lower than set temperature or program ends, the hot-lid will be automatically closed

Communication Interface

USB

LAN

Power supply

100-240V, 50/60Hz, 600W

Dimension

335*260*270mm

345*260*270mm

Packing size(L*W*H)

495*410*395mm

495*410*395mm

Gross weight

10.5KG

12,5KG

Certificates

Ferrotec Peltier/CE/RoHS2.0
