1990 standard 512 DMX control channels.

4 output with separate optical isolated

Up to 32 scanners may be connected with amaximum of 16 channels each.

A large back light LCD to display operation parameters

16 channel faders plus 1 speed and 1 crosscontrol fade.

1600 chase steps maximum. 48 chases - up to 99 steps each. Speed and cross time of each step can be set separately. Speedadjustable by music active or manual mode.

The time range of both SPEED fade and CROSS fade is 0.01s-25.5s and the total time amount of current status will be programstep time

48 scenes can be used directly.

8 chases and 48 scenes can run at the sametime. And 32 scanners can be selected together

The X/Y channels of different fixtures canbe controlled by PAN/TILT wheel together.

16 Bit control for PAN/TILT fineadjustment.

15 environment programs to output thecombination, which are composed of different scenes, chases and manual outputquickly.

The music trigger source can be selected between audio line input or internal microphone.

The Data auto-saves. (Through the electronic memory storage and it can be changed freely)

High performance switching power supply,with extremely low power harmonious distortion and wide range of voltage, suitfor the requirement of different country simultaneously.

LED lamp connector
