Brand：	none
Address：	China
Min.Order：	none
Supply：	none
Valid until：	Long Term

Product Details

Overview

Quick Details

Light Source:: LED

Input Voltage(V):: AC85-277V

Lamp Luminous Flux(lm):: 2400-36000

CRI (Ra>):: 70

Working Temperature(℃):: -50 - 75

Working Lifetime(Hour):: 50000

IP Rating:: IP65

Certification:: BV, CE, EMC, LVD, RoHS, VDE

Warranty(Year):: 5

Brand Name:: SHCET

Model Number:: CET-122A~CET-135

Application:: ROAD

Product name:: led street lighting

Lamp Body Material:: Aluminum

Color Temperature(CCT):: 2700K-6500K

LED Light Source:: SMD3030 OR OTHERS

Lamp Luminous Efficiency(lm/w):: 120

Power Factor:: PF>0.9

LED Driver:: Waterproof Driver

Surge Protector:: 4KV-6KV-10KV

Shine Angle:: 120°

Material:: Die-Alu+Lens

Supply Ability

Supply Ability:: 10000 Piece/Pieces per Day led street lighting

Packaging & Delivery

Packaging Details: 1pc packed in a carton box

Port: Guangzhou

1.Product Description

LED street light refers to the street light made with LED light source, which has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed, high color rendering index, and is of great significance to urban lighting energy saving

2.Specification

SMD LED Street Light

Model	CET-124-30W SMD	CET-124-50W SMD	CET-124-60W SMD	CET-124-100W SMD	CET-124-120W SMD	CET-124-150W SMD	CET-124-200W SMD
Lamp Power	30W	50W	60W	100W	120W	150W	200W
LED Qty	30pcs	55pcs	60pcs	110pcs	120pcs	165pcs	200pcs
Product size(mm)	445x155x66mm	550x200x75mm		700x245x100mm		770x280x100mm
Pole Diameter	Φ50mm	Φ50mm		Φ60mm		Φ60mm
Material	Die-Alu+pc Lens
Power Factor	>0.9
Lamp Flux	80-90LM/1W; 100-120LM/1W; 120-140LM/1W
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
SPD	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey or White; The product can choose to install sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA, Intertek TIR

SMD LED Street Light

Model	CET-126-20W	CET-126-30W	CET-126-50W	CET-126-60W	CET-126-90W	CET-126-100W	CET-126-120W	CET-126-150W	CET-126-180W
Lamp Power	20W	30W	50W	60W	90W	100W	120W	150W	180W
LED Qty	20pcs	30pcs	60pcs	60pcs	100pcs	100pcs	120pcs	180pcs	180pcs
Product size(mm)	315x128x76mm	351x142x76mm	405x166x79mm		484x211x83mm			580x242x83mm
Pole Diameter	Φ40mm	Φ40mm	Φ50mm		Φ60mm			Φ60mm
Material	Die-Alu+pc Lens
Power Factor	>0.9
Lamp Flux	80-90LM/1W; 100-120LM/1W; 120-140LM/1W
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
SPD	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey or White; The product can choose to install sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA, Intertek TIR

SMD LED Street Light

Model	CET-135-20W SMD	CET-135-30W SMD	CET-135-50W SMD	CET-135-100W SMD	CET-135-150W SMD
Lamp Power	20W	30W	50W	100W	150W
Lamp Flux	2400LM	3600LM	6000LM	12000LM	18000LM
Product size(mm)	350x100x60mm	385x145x60mm	540x213x50mm	600x255x50mm	715x255x50mm
Material	Die-Alu+pc diffuser
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA, Intertek TIR

Modular LED Street Light

Model	CET-123-60W SMD	CET-123-90W SMD	CET-123-120W SMD	CET-123-150W SMD	CET-123-180W SMD
Lamp Power	2x30W	3x30W	4x30W	5x30W	6x30W
Lamp Flux	7200LM	10800LM	14400LM	18000LM	21600LM
Product size(mm)	540x360x110mm	640x360x110mm	740x360x110mm	840x360x110mm	940x360x110mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA, Intertek TIR

COB LED Street Light

Model	CET-124-30W COB	CET-124-50W COB	CET-124-100W COB	CET-124-150W COB	CET-124-200W COB	CET-124-250W COB
Lamp Power	30W	50W	2x50W	3x50W	4x50W	5x50W
Product size(mm)	350x150x60mm	500x230x80mm	720x280x80mm	860x330x80mm	950x350x80mm	1100x360x80mm
Power Factor	>0.9
Material	Die-Alu+Lens
Lamp Flux	80-90LM/1W; 100-120LM/1W;
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey The product can choose to install sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES , EAC, ISO9001, SAA, Intertek TIR

COB LED Street Light

Model	CET-125-50W COB	CET-125-100W COB	CET-125-150W COB
Lamp Power	50W	2x50W	3x50W
Product size(mm)	535x240x70mm	720x250x90mm	800x310x100mm
Power Factor	>0.9
Material	Die-Alu+Lens
Lamp Flux	80-90LM/1W; 100-120LM/1W;
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES , EAC, SAA, Intertek TIR

Modular LED Street Light

Model	CET-122A 30W	CET-122A 60W	CET-122A 90W	CET-122A 120W	CET-122A 150W	CET-122A 180W	CET-122A 210W
Lamp Power	1x30W	2x30W	3x30W	4x30W	5x30W	6x30W	7x30W
Product size(mm)	462x315x75mm	548x315x75mm	634x315x75mm	720x315x75mm	806x315x75mm	892x315x75mm	978x315x75mm
Material	Die-Alu+Lens
Power Factor	>0.9
Lamp Flux	80-90LM/1W; 100-120LM/1W; 120-140LM/1W
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES , EAC, ISO9001, SAA, Intertek TIR

Modular LED Street Light

Model	CET-122B 50W	CET-122B 100W	CET-122B 150W	CET-122B 200W	CET-122B 250W	CET-122B 300W
Lamp Power	1x50W	2x50W	3x50W	4x50W	5x50W	6x50W
Product size(mm)	492x315x75mm	608x315x75mm	724x315x75mm	840x315x75mm	956x315x75mm	1072x315x75mm
Material	Die-Alu+Lens
Power Factor	>0.9
Lamp Flux	80-90LM/1W; 100-120LM/1W; 120-140LM/1W
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	2.5KV-4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES , EAC, ISO9001, SAA, Intertek TIR

3.Features

LED street lamp is different from conventional street lamp. LED light source uses low-voltage DC power supply, high-efficiency white light synthesized by GaN-based power blue LED and yellow. It has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed and high color rendering index, and can be widely used in road. The outer cover can be made, high temperature resistance up to 135 degrees, and low temperature resistance up to -45 degrees.

4.Installation Guide

1.Cut off the main power supply.

2.Install the light pole, then tightly attach the pole to the lamp arm.

3.Connect the power cord, and extend the three cables from the base to the lamp arm. The yellow cable is the bottom line, the blue cable is the zero line, and the brown cable is the live line.

4.Tighten the screws, and attach the light to the pole.

5.Connect the main power supply.

5.More Products

6.Application

LED street lights are mainly used for road lighting, such as trunk road, sub-trunk road, branch road, factory, school, garden, city square, courtyard and so on.

7.Packaging&Shipping

8.Certificate

9.FAQ

Q1: Can I have a sample for testing?

A: Yes, we can offer free sample, but you should afford the shipping cost.

Q2: Can I add my logo on the products?

A: Yes, OEM and ODM are available for us.

Q3: How can I get the after-service?

A: We will send you the free spare parts if the problems caused by us. If the products cannot be repaired, we will send you new free quantity together with next order.

Q4: Do you have inspection procedures for products?

A: our products100% self-inspection and testing before packing.

Q5: Can I have a visit to your factory before the order?

A: Sure, welcome to visit our factory.

Here is our factory address: #7 Tongyi Industrial Area, Zhongshan City, Guzhen

Our factory is near Guangzhou airport, and we can pick you up in the airport, Hotel booking service is available.

Q6: How about delivery time of the order?

A: 15-20 days after getting deposit.

Q7: How about payment terms?

A: 20%-30% deposit, the rest payment balance against B/L. If have regular order and good order quantity, we can give delay payment.
