We buy high quality quartz tube and cut according require by customers , some equipments are imported from Japan and Germany , we design our machine to coil the filament , we use white reflector material from GE and gold reflector material from Heraeus to make sure our high quality products .
Brand： |
none |
Address： |
China |
Min.Order： |
none |
Supply： |
none |
Valid until： |
Long Term |
Product Details
Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- Halo-infrared
- Color:
- golden
- Specification:
- 48V - 600V
- Material:
- Quartz tube
- Certification:
- CE
- Working Lifetime(Hour):
- 5000 hours
- Beam Angle(°):
- 180 degree
- Wattage:
- 100 - 12000 W
- Base:
- Twin tube ceramic
- Lifetime:
- 5000 hours
- Cable wire:
- Teflon / UL textile wire
- Heating element:
- Tungsten filament
- Peak wavelength:
- 1.2 - 1.4 μm
- Response time:
- 1 - 2 seconds
- Installation:
- Horizontal
- Filament temperature:
- 1800 - 2200 ℃
- Customized:
- Yes
Supply Ability
- Supply Ability:
- 500 Piece/Pieces per Week for infrared halogen heater twin tube lamp Heraeus 09751751
Packaging & Delivery
- Packaging Details
- Each infrared lamp is covered with soft material .
Then packaged into a individual white box .
30-50 white boxes are put into a strong paper carton or wooden case .
- Port
- ShangHai
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 20 >20 Est. Time(days) 10 To be negotiated
Specification
Product Information | ||
Finished | Gold Reflector | |
Rated Voltage | 230V | |
Rated Wattage | 1500W | |
Wavelength | Shortwave | |
Installation | Horizontal | |
Heating material | Tungsten filament | |
Certificate | CE | |
Lifetime | 5000 hours | |
Product Description
Product Details
Model | HSC-8710 | HSC-8711 | HSC-8712 |
Voltage | 110V | 220V | 600V |
Wattage | 3000W | 7000W | 9000W |
Finished | Gold reflector | Gold Reflector | Gold reflector |
Installation Process
Applications
--Textile industry
--Plastics industry
--Printing ink
--Curing of paint, Powder coating , Lacquers Drying
--Automotive industry etc.
Package detail
Certifications
FAQ
Q1. Can I have a sample order for shortwave infrared heating lamps ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. How to choose correct heating solution ?
A:We have rich experience engineers , we work with different field , we collected a lot of technical data to solve the heating problem .
Q3. Do you have any MOQ limit for shortwave infrared heating lamps order ?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive ?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for shortwave infrared heating lamps ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on shortwave infrared heating lamps ?
A: Yes. Please inform us formally before our production , the logo will be printed on the ceramic area of the lamps
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: What about the lead time?
A:Sample needs 7-10 days, bigger quantity order will cost 1-2 weeks
