Product Details
Product Specifications
High output UV-C germicidal lamp is worldwide used for water disinfection and air sterilization units. High ozone and ozone free could be flexibly made according to customers needs. 254nm without ozone operation is suggested for disinfection, and 185nm high ozone type is for odor control.
| Model | Tube Diameter | Length | Power | Current | UVC output | Output Power | Rated Lifespan/ hours | |
| mm | mm | Watt | mA | μW/cm² | Watt | Standard | Longlife | |
| High output type-Ozone free/ T5 series | ||||||||
| GHO212T5L | 15 mm | 212 mm | 18W | 800mA | 50 | 5 | 10000 | 13000 |
| GHO287T5L | 15 mm | 287 mm | 27W | 800mA | 75 | 7.5 | 10000 | 13000 |
| GHO357T5L | 15 mm | 357 mm | 32W | 800mA | 95 | 10 | 10000 | 13000 |
| GHO436T5L | 15 mm | 436 mm | 48W | 800mA | 120 | 13 | 10000 | 13000 |
| GHO793T5L | 15 mm | 793mm | 72W | 800mA | 210 | 24 | 10000 | 13000 |
| GHO846T5L | 15 mm | 846 mm | 80W | 800mA | 260 | 28 | 10000 | 13000 |
| GHO893T5L | 15 mm | 893 mm | 90W | 800mA | 270 | 30 | 10000 | 13000 |
| GHO1148T5L | 15 mm | 1148 mm | 120W | 800mA | 310 | 30 | 10000 | 13000 |
| GHO1554T5L | 15 mm | 1554 mm | 145W | 800mA | 400 | 45 | 10000 | 13000 |
| High output-High Ozone/ T5 series | ||||||||
| GHO212T5VH | 15 mm | 212 mm | 18W | 800mA | 50 | 5 | 10000 | 13000 |
| GHO287T5VH | 15 mm | 287 mm | 27W | 800mA | 75 | 7.5 | 10000 | 13000 |
| GHO357T5VH | 15 mm | 357 mm | 32W | 800mA | 95 | 10 | 10000 | 13000 |
| GHO436T5VH | 15 mm | 436 mm | 48W | 800mA | 120 | 13 | 10000 | 13000 |
| GHO793T5VH | 15 mm | 793mm | 72W | 800mA | 210 | 24 | 10000 | 13000 |
| GHO846T5VH | 15 mm | 846 mm | 80W | 800mA | 260 | 28 | 10000 | 13000 |
| GHO893T5VH | 15 mm | 893 mm | 90W | 800mA | 270 | 30 | 10000 | 13000 |
| GHO1148T5VH | 15 mm | 1148 mm | 120W | 800mA | 310 | 30 | 10000 | 13000 |
| GHO1554T5VH | 15 mm | 1554 mm | 145W | 800mA | 400 | 45 | 10000 | 13000 |
Benefit
◪ “HO” high output UV germicidal lamp is specially made to offer more than half higher UV-C output even at the same length and shape.
◪ We could decrease the lamp quantity to keep same disinfection effect.
◪ Cost-effectiveness and space-saving solution for higher sterilization performance.
Application
