LED Medium double reflector aviation warning flash obstruction tower airplane warning lights
Product Detail
| Overall Size | Diameter:210*140mm |
| Color | Red/White |
| Light Intensity | 20000cd(white)/2000cd(Red) |
| Power Consumption | ≤40W(day), ≤15W(night) |
| Beam angle for obstruction light | 360° horizontal beam angle ≥4° vertical beam spread |
| Flashing frequency obstruction lights | 20-60times/min |
| Lightning protection level | 15KA |
| Light controlled sensitivity | 100lux |
| Net weight | 7KG |
| Used in | Airport,helipads,chimney,iron tower,building,civil airports |
| Product Keywords | tower airplane warning lightsLED obstruction airplane lights aviation warning flash |
Widely used in various fields of the Air Force, civil airports and obstacle free airspace, helipads, iron tower, chimney, ports, wind power plants, bridge and city high-rise buildings where require aviation warning.
Shipping
Fast Delivery
Different amount of time will be required for different
Features
Applicaions
Hunan Chendong Technology co., LTD is a professional company, which is focus on producing aviation obstruction light,helipad lighting and aircraft warning lights. It is located in Hunan, China. We have our own factory, so we can control the quality, arrange production plan and so on. We provide PVC foam board with different densities, different thicknesses, different sizes based on your requirements. Our aviation obstruction light are widely sold in the Middle East, South Asia, Africa and other parts of the world. We are looking forward to cooperating with you
In order to supply the best aviation obstruction light, from raw materials to the final inspection, we choose top quality materials, the advanced equipments,experienced worker, strict quality control to guarantee the aviation obstruction light quality.
1,high temperature test
2,rainfall test
3,salt spray
4,temperature and humidity test
5,vibration test
