Product Details
[[NAME]]
Specifications of [[KEY]]:
Housing: 0.5mm steel sheet with white powder coated.
Diffuser: 2.2 Clear PC material.
End Caps: White ABS material
Electrical Parts: Without ballast; With T5/T8 VDE lampholders or prewired;
Installation: Ceiling or wall mounted.
Picture of [[KEY]]:
[[ALL_IMG]]
Product dimension of [[KEY]]:
| Model | Lamp | Lamp Size | Package size | pcs/ctn |
| HG201-Y14x2 | T5,2x14W | 645x208x70mm | 675x385x220mm | 5 |
| HG201-Y28x2 | T5,2x28W | 1200x208x70mm | 1235x385x220mm | 5 |
| HG201-Y18x2 | T8,2x18W | 600x208x70mm | 635x385x220mm | 5 |
| HG201-Y36x2 | T8,2x36W | 1255x208x70mm | 1285x385x220mm | 5 |
Electrical:
Standard T5 and T5HO: Program start 120/277 volt integral electronic ballast or 247V VDE electronic ballast with less than 10% THD.
Each ballast provided with disconnects to meet luminaire disconnect code requirement.
Mounting:
The product is designed to install into acoustical grid and inaccessible ceilings.
Finish:
Prepainted white polyester polymer finish on expose trim;
Optional paint after fabrication available if specified.
Labels:
UL and cUL Listed, approved for dry/damp location unless otherwise noted.
Options:
-Available for installing with the Frosted Lens
-Available for installing with LED module.
-Available for installing with sensor
Photometric data:
