Power

high efficiency and reliable switching power supply

Color plate

a color plate, each color plate consists of 14 color film + white light

Pattern plate

17 gobo effects

Effect wheel

a rotatable honeycomb(Cellular ) prism and a 6 linear prism

Colorful features

with colorful function (rainbow effect)

Dimming

0-100% electronic dimming

Beam angle adjustable range

Strobe

Support mechanical strobe and strobe effects, strobe macro support

Lens set optical system, electric focus, beam angle 3.8 ° -45 ° linearly adjustable

The use of optical reset system, when accidental misoperation, can automatically retrieve the reset

Level 540 °, resolution 8Bit / 16Bit

Vertical 270 °, resolution 8Bit / 16Bit

Overheating protection

Control mode

DMX512 / master / slave

Protection level

IP20

Channel

17/20 CH

N.W

19kgs
