Brand：	none
Address：	China
Min.Order：	none
Supply：	none
Valid until：	Long Term

Product Details

Overview

Quick Details

Input Voltage(V):: AC100-260V

Lamp Power(W):: 30

CRI (Ra>):: 80

Lamp Luminous Flux(lm):: 5500

IP Rating:: IP65

Working Lifetime(Hour):: 100000

Working Temperature(℃):: -40 - 60

Certification:: BV, CCC, CE, FCC, RoHS

Place of Origin:: Zhejiang, China

Brand Name:: GT

Light Source:: LED

Input Power:: AC100-260V 50-60Hz

Luminous Flux:: 5500 Lm

Light Source Life:: 100000 h

Lamp Size:: 220*170 mm

Lamp Weight:: 3.5 Kgs

Color Temperature:: 5700 K

Anti-corrosion grade:: WF2

Ex-mark:: Exd IIC T6

Insulation grade:: I

Lamp Luminous Efficiency:: >88%

Product Certification Verified

CE Certified.: Valid from 2018-03-06 until 2023-03-05

FCC Certified.: Valid from 2018-02-02 until 2049-12-31

RoHS Certified.: Valid from 2018-02-02 until 2049-12-31

Supply Ability

Supply Ability:: 1000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: Carton

Port: Shanghai/Ningbo

Lead Time:

Quantity(Pieces)	1 - 50	51 - 100	101 - 500	>500
Est. Time(days)	10	15	30	To be negotiated

PRODUCT INTRODUCTION

Technical Parameters:

Item	Parameters
Light Source	30 W
Input Power	AC100-260V 50-60Hz
Luminous Flux	5500 Lm
Light Source Life	100000 h
Power Factor	>98 %
Luminaire Efficiency	>88 %
Lamp Size	Φ220×170 mm
Lamp Weight	3.5 Kgs
Color Temperature	5700 K
Space-depth ratio	1.4 S/h
Inlet thread	3/4 G
Lead-in cable	Φ6-10 mm
Anti-corrosion grade	WF2
Insulation grade	Ⅰ
Protection grade	IP65
Ex-mark	Exd IIC T6

FEATURES

1.CE, ROHS, FCC, ATEX certified.

2.LED light source, power consumption is 20% of Incandescent light.

3.Soft white LED light with no glare, perfect electromagnetic compatibility.

4.Modular design, easy to maintain and replace.

5.Casing adopt AL die-casting molding & electrostatic spraying surface.

6.Different installation methods to meet different need.

APPLICATION PHOTOS

If you have any question, please feel free to contact:

Sales 1: Edward Lin

Skype: edward_9031

Mobile: +86 150 5719 8569

Xianheng International Science&Technology Co., Ltd.

Tel: +86-571- 8792 6828 Fax: +86-571-8504 8393

Welcome to visit our factory, you won"t be disappointed !
