Product Details

Overview

Quick Details

Input Voltage(V):: AC85-277V

Lamp Luminous Flux(lm):: 2400-36000

CRI (Ra>):: 70

Working Temperature(℃):: -50 - 75

Working Lifetime(Hour):: 50000

IP Rating:: IP65

Certification:: BV, CE, EMC, LVD, RoHS, VDE

Warranty(Year):: 5

Place of Origin:: Guangdong, China

Brand Name:: SHCET

Model Number:: CET-122A~CET-135

Application:: ROAD

Product name:: led street lighting

Lamp Body Material:: Aluminum

Color Temperature(CCT):: 2700K-6500K

LED Light Source:: SMD3030 OR OTHERS

Lamp Luminous Efficiency(lm/w):: 120

Power Factor:: PF>0.9

LED Driver:: Waterproof Driver

Surge Protector:: 4KV-6KV-10KV

Shine Angle:: 120°

Material:: Die-Alu+Lens

Light Source:: LED, Incandescent Bulbs, HID, Fluorescent, Halogen Bulbs, Induction Lamps, Ultraviolet Lamps, Neon Bulbs

Item Type:: Street Lights

Supply Ability

Supply Ability:: 10000 Piece/Pieces per Day led street lighting

Packaging & Delivery

Packaging Details: 1pc packed in a carton box

Port: Guangzhou

1.Product Description

LED street light refers to the street light made with LED light source, which has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed, high color rendering index, and is of great significance to urban lighting energy saving

2.Specification

Model	CET-122A 30W	CET-122A 60W	CET-122A 90W	CET-122A 120W	CET-122A 150W	CET-122A 180W	CET-122A 210W
Lamp Power	1x30W	2x30W	3x30W	4x30W	5x30W	6x30W	7x30W
Lamp Flux	3600LM	7200LM	10800LM	14400LM	18000LM	21600LM	25200LM
Product size(mm)	462x315x75mm	548x315x75mm	634x315x75mm	720x315x75mm	806x315x75mm	892x315x75mm	978x315x75mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-122B 50W	CET-122B 100W	CET-122B 150W	CET-122B 200W	CET-122B 250W	CET-122B 300W
Lamp Power	1x50W	2x50W	3x50W	4x50W	5x50W	6x50W
Lamp Flux	6000LM	12000LM	18000LM	24000LM	30000LM	36000LM
Product size(mm)	492x315x75mm	608x315x75mm	724x315x75mm	840x315x75mm	956x315x75mm	1072x315x75mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-123-60W SMD	CET-123-90W SMD	CET-123-120W SMD	CET-123-150W SMD	CET-123-180W SMD
Lamp Power	2x30W	3x30W	4x30W	5x30W	6x30W
Lamp Flux	7200LM	10800LM	14400LM	18000LM	21600LM
Product size(mm)	540x360x110mm	640x360x110mm	740x360x110mm	840x360x110mm	940x360x110mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-124-30W COB	CET-124-50W COB	CET-124-100W COB	CET-124-150W COB	CET-124-200W COB	CET-124-250W COB
Lamp Power	30W	50W	2x50W	3x50W	4x50W	5x50W
Lamp Flux	3600LM	6000LM	12000LM	18000LM	24000LM	30000LM
Product size(mm)	495x200x60mm	640x250x80mm	720x275x80mm	890x340x80mm	950x350x80mm	1100x360x80mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey The product can choose to install sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-124-30W SMD	CET-124-50W SMD	CET-124-60W SMD	CET-124-100W SMD	CET-124-120W SMD	CET-124-150W SMD
Lamp Power	30W	50W	60W	100W	120W	150W
Lamp Flux	3600LM	6000LM	7200LM	12000LM	14400LM	18000LM
Product size(mm)	550x200x75mm	550x200x75mm	550x200x75mm	700x245x100mm	700x245x100mm	770x280x100mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey The product can choose to install sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-125-50W COB	CET-125-100W COB	CET-125-150W COB
Lamp Power	50W	2x50W	3x50W
Lamp Flux	6000LM	12000LM	18000LM
Product size(mm)	535x240x70mm	720x250x90mm	800x310x100mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-126-20W SMD	CET-126-30W SMD	CET-126-50W SMD	CET-126-60W SMD	CET-126-90W SMD	CET-126-100W SMD	CET-126-120W SMD	CET-126-150W SMD
Lamp Power	20W	30W	50W	60W	90W	100W	120W	150W
Lamp Flux	2000LM	3000LM	5500LM	6000LM	9900LM	10000LM	12000LM	18000LM
Product size	31313555 mm	36213955 mm	42015955 mm	42015955 mm	49618073 mm	49618073 mm	49618073 mm	55320473 mm
LED chips QTY	20PCS	30PCS	60PCS	60PCS	100PCS	100PCS	120PCS	180PCS
LED chips Type	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W	3030/2835 SMD 1W
Material	Die-casting aluminume+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-305V
Body Color	Black or Grey The product can choose to install light sensor
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001

Model	CET-134-30W COB	CET-134-50W COB	CET-134-100W COB	CET-134-150W COB	CET-134-200W COB	CET-134-250W COB
Lamp Power	30W	50W	2x50W	3x50W	4x50W	5x50W
Lamp Flux	3600LM	6000LM	12000LM	18000LM	24000LM	30000LM
Product size(mm)	500x230x90mm	540x230x90mm	680x260x90mm	810x290x90mm	980x285x100mm	1130x301x103mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

Model	CET-135-20W SMD	CET-135-30W SMD	CET-135-50W SMD	CET-135-60W SMD	CET-135-100W SMD	CET-135-120W SMD	CET-135-150W SMD
Lamp Power	20W	30W	50W	60W	100W	120W	150W
Lamp Flux	2400LM	3600LM	6000LM	7200LM	12000LM	14400LM	18000LM
Product size(mm)	347x95x65 mm	400x130x65 mm	540x213x50 mm	520x220x70 mm	598x255x45 mm	550x250x70 mm	714x255x50 mm
Material	Die-Alu+Lens
Power Factor	>0.9
Color Temperature	3000-3500K; 4000-4500K; 6000-6500K
IP Grade	IP65
CRI	Ra>70
Life Time	50000H
Surger Protector	4KV-6KV-10KV
Input Voltage	AC85-277V
Body Color	Black or Grey
Certificate	BIS ,SASO ,CE-LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001, SAA

3.Features

LED street lamp is different from conventional street lamp. LED light source uses low-voltage DC power supply, high-efficiency white light synthesized by GaN-based power blue LED and yellow. It has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed and high color rendering index, and can be widely used in road. The outer cover can be made, high temperature resistance up to 135 degrees, and low temperature resistance up to -45 degrees.

4.Installation Guide

1.Cut off the main power supply.

2.Install the light pole, then tightly attach the pole to the lamp arm.

3.Connect the power cord, and extend the three cables from the base to the lamp arm. The yellow cable is the bottom line, the blue cable is the zero line, and the brown cable is the live line.

4.Tighten the screws, and attach the light to the pole.

5.Connect the main power supply.

5.More Products

6.Application

LED street lights are mainly used for road lighting, such as trunk road, sub-trunk road, branch road, factory, school, garden, city square, courtyard and so on.

7.Packaging&Shipping

8.Certificate

9.FAQ

Q1: Can I have a sample for testing?

A: Yes, we can offer free sample, but you should afford the shipping cost.

Q2: Can I add my logo on the products?

A: Yes, OEM and ODM are available for us.

Q3: How can I get the after-service?

A: We will send you the free spare parts if the problems caused by us. If the products cannot be repaired, we will send

you new free quantity together with next order.

Q4: Do you have inspection procedures for products?

A: our products100% self-inspection and testing before packing.

Q5: Can I have a visit to your factory before the order?

A: Sure, welcome to visit our factory.

Here is our factory address: #7 Tongyi Industrial Area, Zhongshan City, Guzhen

Our factory is near Guangzhou airport, and we can pick you up in the airport, Hotel booking service is available.

Q6: How about delivery time of the order?

A: 15-20 days after getting deposit.

Q7: How about payment terms?

A: 20%-30% deposit, the rest payment balance against B/L. If have regular order and good order quantity, we can give

delay payment.
