Product Details
| Type | Wattage | Temperature | Beam | Voltage | CRI | Light source | Life(H) | Size |
| TK027 | □16W | □2700K □3000K □3500K □4200K □5700K | □10° □20° □30° | AC220V | ≧80 | CREE | 30000 | 169X124X75mm |
| □24W | □10° □15° □20° □30° |
- Delicate appearance, modeling unique.
- Aircraft grade aluminum material, with sophisticated technology, fine workmanship and quality excellence.
- Spraying powder on the surface of gentle and smooth, its not fade and easy to maintenance.
- Precise control light, uniform luminance, widely application.
- Low power, high luminous efficacy, less energy cost.
- Green light source and material, no radiation, no harmful substances.
4000 Square Meter factory area ,Strict Quality Control System ;
Design & Produce Ourselves, 12 Years LED Business Experience;
More than 3 Years Lighting Market Share Experience;
Special Design For Oceania, Europe, America etc.
What is the details of our led Track Lighting Fixtures?
1. Ultra-thin design, light weight LED Modern Track Lighting solution.
2. Pure aluminum better for heat dissipation.
3. Isolated constant current driver with long lifespan.
4. Design patent certificates, Track Lighting application patent.
5. High quality Track Spotlights with a colour rendering index of 80.
Sumbao
Professional Lighting
Using co focal reflection lens of high precision, high purity optical PMMA material, the light source sends out the full and effective used of and certain angle to emit uniform and soft light. Not only focus on the highlight the features of products, but also make the environment more comfortable and peaceful.
Sumbao
Professional Lighting
Imported CREE light source of high luminous efficacy, high color rendering and consistency, the light is soft.
Sumbao
Professional Lighting
Made of industrial pure Al, based on chimney design, good at heating dissipation, it does improve the service life.
The horizontal rotation of 350 degrees + The vertical direction of 350 degrees. Using the latest technology in rotation, it can adjust the lamp to easy meet different demands for light in all directions.
It is easy to install, simple and fast to adjust.
- Beam
Graph - 11°
- 14°
- 27°
The average of effective luminous
The picture is based on the light distribution curve test data. When the light beam angle is 14°, the color temperature is 3000K and the object is in the 2.5M, as the central luminance will be 2500.56lx and the aperture area of 0.60m. The more small distance, the central luminance is higher, and the aperture area is smaller. Conversely, it has the reverse effect.
Facular color temperature contrast
LED chip is with high luminous efficacy, pure color and greater consistency. Color selection is variety, not only can meet the requirement of shop lighting for color consistency, and can meet the need of different colors of goods of special color temperature. (Such as furniture, clothing shop etc.)
The 3000K warm white is suitable for deep color furniture exhibition.
The 4000K anature white is appropriate for light color fumiture, supermarket,clothing store etc.
The 5000K cold white is apply for modern furniture, upscale market, exclusive shop.
Comparison of spot beam Lens is designed in several of angles; it’s greatly to meet the needs of different light application. Not only satisfied to the small angle light for commodities, but also can render the surrounding light environment by changing large light. It’s achieved the perfect combination of accent lighting and ambient lighting.
11°
17°
27°
Color performance is very high, it can restore the commodity color, texture and color of the goods can presented perfectly, especially suitable for shopping center, clothing store, supermarket, exhibition room, furniture store etc.

|
The installation instruction
1: The railway is fixed on the ceiling, and then makes the circuit connected.
2: The contact copper sheet shifting to the position which parallel to the track, and put into orbit, toggle dial handle 90 degrees to make the lamp copper card in orbit(Note: if the light is 3 lines, you should first make the contact copper sheet aim at tract direction. The electric box has prompted a slogan, please operating to the prompt sign)
3: Check whether the lamp is installed firmly, then you can turn on the light.
4: If you want to adjust the direction of the lamp, please hold the lamp holder, and move around.
5: Here is the installation is complete.
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.
Sample Policy Service:
We provide free samples in this way - Refund sample fees when bulk order (100pcs at least),
For example, refund 1 sample fee when ordering 100pcs lamp.
Customized Service:
Share us your led track light design or your idea, we will design & open mold for you.
you will enjoy the exclusive right of this lamp on your local markets.
we will sign the exclusive agreement.
After-sales Service:
Free replacement in warranty period if the quality problems,we will undertake the shipping cost.
Payment Terms
Payment: T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery.
MOQ: 1pcs
Warranty: 3 years.
Package Informations: 86 pcs per box/The volume of the box is 49cmx37cmx30cm
